R067203000 | BOSCH REXROTH | Super Linear Bushing
₹ 12,698.37
₹ 10,761.33 (Excl. Tax)
No se ha podido cargar la disponibilidad de recogida
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Speeds of up to 5 m/s possible. Service life is limited by heightened wear to plastic parts. Tests have shown total travel from 50 • 10⁵ m to 100 • 10⁵ m without failure.
Length of linear bushing [mm]
68.0
Outer diameter D [mm]
47.0
Permissible ambient temperature (min. ... max.)
-10 °C ... +80 °C
Friction coefficient μ
0.001 ... 0.0025
Note: friction coefficient μ
Friction coefficients of unsealed linear bushings when lubricated with oil. The friction coefficient is lowest under heavy load, but can still be above the specified value even under a low load.
Weight [kg]
0.2
Footnote breakaway force
One wiper seal: Multiply value with factor 0.5
Footnote maximum dynamic load capacity Cmax
The dynamic load capacities are based on a total travel of 100,000 m. When based on 50,000 m, the C values in the table are to be multiplied by 1.26.
Footnote minimum dynamic load capacity Cmin
The dynamic load capacities are based on a total travel of 100,000 m. When based on 50,000 m, the C values in the table are to be multiplied by 1.26.
Footnote friction force FR
1. One wiper seal: Multiply value with factor 0.5 2. Frictional drags generated by linear bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication.
Breakaway force [N]
6
Dimension C h13 [mm]
68
Dimension C1 H13 [mm]
51.7
Dimension C2 [mm]
1.85
Dimension D [mm]
47
Dimension D1 [mm]
44.5
Su carrito
BOSCH REXROTH
R067203000 | BOSCH REXROTH | Super Linear Bushing
₹ 10,761.33
Precio unitario /
Agotado
Specification
Details
Shaft diameter d [mm]
30.0
Version
Standard
Format of linear bushings
Closed
Series
Super B (no self-alignment feature)
Type
Linear bushing
Seal
Without wiper seals
Lubrication
Not lubricated
Maximum dynamic load capacity Cmax [N]
5860.0
Maximum acceleration rate amax [m/s²]
150.0
Maximum permissible linear speed vmax [m/s]
3.0
Note: maximum permissible speed vmax
Speeds of up to 5 m/s possible. Service life is limited by heightened wear to plastic parts. Tests have shown total travel from 50 • 10⁵ m to 100 • 10⁵ m without failure.
Length of linear bushing [mm]
68.0
Outer diameter D [mm]
47.0
Permissible ambient temperature (min. ... max.)
-10 °C ... +80 °C
Friction coefficient μ
0.001 ... 0.0025
Note: friction coefficient μ
Friction coefficients of unsealed linear bushings when lubricated with oil. The friction coefficient is lowest under heavy load, but can still be above the specified value even under a low load.
Weight [kg]
0.2
Footnote breakaway force
One wiper seal: Multiply value with factor 0.5
Footnote maximum dynamic load capacity Cmax
The dynamic load capacities are based on a total travel of 100,000 m. When based on 50,000 m, the C values in the table are to be multiplied by 1.26.
Footnote minimum dynamic load capacity Cmin
The dynamic load capacities are based on a total travel of 100,000 m. When based on 50,000 m, the C values in the table are to be multiplied by 1.26.
Footnote friction force FR
1. One wiper seal: Multiply value with factor 0.5 2. Frictional drags generated by linear bushings with integrated wiper seals on two sides when not under radial load. The frictional drags depend on speed and lubrication.
