SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC

This product has been discontinued, and manufacturer warranty or support may no longer be available.

PM210MG | SCHNEIDER ELECTRIC | PM210 power meter unit with backlite green LCD display

₹ 33,630.00

₹ 28,500.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

PM210MG

Original Equipment Manufacturer

SCHNEIDER ELECTRIC

Descripción
Model / Part No. PM210MG (PowerLogic PM210 series)
Display Back‑lit green LCD, 6 lines (4 values + menu row)
Measured Parameters Voltage, Current, Active/Reactive/Apparent Power, Power Factor, Frequency, Energy (kWh, kvarh, kvarh), Demand
Voltage Input Range 100–415 V AC, 50/60 Hz; 125–250 V DC
Current Input Nominal 5 A, max 6 A
Accuracy ±1% for power; ±0.5% for voltage and current
Communication Interface RS‑485 port, Modbus RTU, baud rates: 2400–19200; parity: Even/Odd/None
Power Consumption 5 VA nominal
Operating Temperature −40…+85 °C
Insulation / IP Rating IP30 rear, IP52 front (IEC 60529), Pollution 2
Safety / Standards IEC 61010‑1, UL 508, CE, cULus
Discontinued Yes; discontinued on Sep 9, 2020, End‑of‑Service Dec 31, 2016; replacement suggested by Schneider
Weight ≈ 0.85 lb (≈ 0.38 kg)
SCHNEIDER ELECTRIC

PM210MG | SCHNEIDER ELECTRIC | PM210 power meter unit with backlite green LCD display

₹ 28,500.00
Model / Part No. PM210MG (PowerLogic PM210 series)
Display Back‑lit green LCD, 6 lines (4 values + menu row)
Measured Parameters Voltage, Current, Active/Reactive/Apparent Power, Power Factor, Frequency, Energy (kWh, kvarh, kvarh), Demand
Voltage Input Range 100–415 V AC, 50/60 Hz; 125–250 V DC
Current Input Nominal 5 A, max 6 A
Accuracy ±1% for power; ±0.5% for voltage and current
Communication Interface RS‑485 port, Modbus RTU, baud rates: 2400–19200; parity: Even/Odd/None
Power Consumption 5 VA nominal
Operating Temperature −40…+85 °C
Insulation / IP Rating IP30 rear, IP52 front (IEC 60529), Pollution 2
Safety / Standards IEC 61010‑1, UL 508, CE, cULus
Discontinued Yes; discontinued on Sep 9, 2020, End‑of‑Service Dec 31, 2016; replacement suggested by Schneider
Weight ≈ 0.85 lb (≈ 0.38 kg)
