SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC
This product has been discontinued, and manufacturer warranty or support may no longer be available.
OSMC32N2C10 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker – Osmart C32N, 2-Pole, 10A, C Curve, 400VAC, 6kA
₹ 2,242.00
₹ 1,900.00 (Excl. Tax)
OSMC32N2C10 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker – Osmart C32N, 2-Pole, 10A, C Curve, 400VAC, 6kA
está agotado y se enviará tan pronto como vuelva a estar disponible.
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
OSMC32N2C10 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker – Osmart C32N, 2-Pole, 10A, C Curve, 400VAC, 6kA
OSMC32N2C10 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker – Osma...
OSMC32N2C10 | SCHNEIDER ELECTRIC | Miniature Circuit Breaker – Osmart C32N, 2-Pole, 10A, C Curve, 400VAC, 6kA
está agotado y se enviará tan pronto como vuelva a estar disponible.
Manufacturer Part Number (MPN)
OSMC32N2C10
Original Equipment Manufacturer
SCHNEIDER ELECTRIC
Descripción
Device Type
Miniature Circuit Breaker, Thermal‑Magnetic
Poles
2P (2‑pole)
Rated Current (In)
10 A
Trip Curve
C‑Curve (fast trip for short‑circuit)
Rated Voltage
400–440 VAC
Breaking Capacity (Icu)
6 kA @ 400 VAC
Functions
Long‑time + Instantaneous (LI)
Connection
Bolt‑on or Clip‑on mounting
Phase
Single‑phase (1P+N)
Standards Compliance
IEC 60947‑2 / EN 60898
Insulation / Impulse Withstand
Ui 500 VAC; Uimp 6 kV
Terminal Capacity
Supports up to 16 mm² flexible or 25 mm² solid conductors
Torque (Terminals)
~2.0–2.5 N·m
Durability
Mechanical ≥20,000 cycles
Temperature Range
−25 °C to +70 °C operation; −40 °C to +85 °C storage
IP / IK Rating
IP20; IK04
Weight
≈ 0.24 kg
Certifications
IEC/EN 60947‑2, UL 1077 (US), CCC; RoHS / Green Premium compliant
Unit Width
2 modules (≈18 mm)
