MDMF302L1G6M | PANASONIC | Servo Motor

₹ 151,997.97

₹ 128,811.84 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

MDMF302L1G6M

Original Equipment Manufacturer

PANASONIC

Descripción

Type Middle inertia
Product Details Middle inertia, Connector type
Family Name MINAS A6
Power Supply Capacity (kVA) 5.2
Voltage Specifications (V) 200
Rated Output (W) 3000
Rated Current (A rms) 16.4
Holding Brake Without
Mass (kg) 9.3
Oil Seal With
Shaft Key-way
Rated Torque (N⋅m) 14.3
Continuous Stall Torque (N⋅m) 15.0
Momentary Max. Peak Torque (N⋅m) 43.0
Max. Current (A 0-p) 70
