CP96SDB40-100 | SMC CORPORATION | C95 C96 Tie-Rod Cylinder

₹ 11,456.83

₹ 9,709.18 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

CP96SDB40-100

Original Equipment Manufacturer

SMC CORPORATION

Descripción
Specification Detail
Model CP96SDB40-100
Series CP96
Type Double Acting, Single Rod
Bore Size 40 mm
Stroke Length 100 mm
Mounting Type Basic, Axial Foot, Rod Flange, Head Flange, Single Clevis, Double Clevis
Port Size G 1/4
Cushioning Air cushion on both ends + Bumper cushion
Lubrication Not required (Non-lube)
Operating Temperature Range Without auto switch: –20 to 70°C; With auto switch: –10 to 60°C
Operating Pressure Range 0.05 to 1.0 MPa
Proof Pressure 1.5 MPa
Piston Speed 50 to 1000 mm/s
Stroke Tolerance Up to 500 mm: +2.0 mm; 501 to 1000 mm: +2.4 mm; 1001 to 1500 mm: +2.8 mm; 1501 to 2000 mm: +3.2 mm
