C96SDD63-125C | SMC CORPORATION | Tie-Rod Cylinder

₹ 16,591.18

₹ 14,060.32 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

C96SDD63-125C

Original Equipment Manufacturer

SMC CORPORATION

Descripción
Feature Specification
Product Type Double Acting, Single Rod Pneumatic Cylinder
Bore Size 63 mm
Stroke Length 125 mm
Mounting Type Double Clevis
Mounting Standard ISO 15552
Action Double Acting
Fluid Compressed Air
Proof Pressure 1.5 MPa
Maximum Operating Pressure 1.0 MPa
Minimum Operating Pressure 0.05 MPa
Ambient and Fluid Temperature -20°C to +70°C (without auto switch), -10°C to +60°C (with auto switch)
Lubrication Not required (Non-lube)
Operating Piston Speed 50 to 1000 mm/s
Allowable Stroke Tolerance Up to 500 mm stroke: +2.0 mm, 501 to 1000 mm stroke: +2.4 mm
Cushion Air Cushion on Both Ends + Bumper Cushion
Port Size G 1/4
Mounting Options Basic, Axial Foot, Rod End Flange, Head End Flange, Single Clevis, Double Clevis, Adjustable Position Trunnion
Non-Rotating Accuracy ±0.3°
Allowable Rotational Torque 0.79 N·m
