SPARECRUX is NOT an authorized distributor for SCHNEIDER ELECTRIC
This product has been discontinued, and manufacturer warranty or support may no longer be available.
A9N1P03C | SCHNEIDER ELECTRIC | Acti9 xC60 Miniature Circuit Breaker, 1 Pole, 3A, C Curve, 10kA
₹ 363.75
₹ 308.27 (Excl. Tax)
A9N1P03C | SCHNEIDER ELECTRIC | Acti9 xC60 Miniature Circuit Breaker, 1 Pole, 3A, C Curve, 10kA
está agotado y se enviará tan pronto como vuelva a estar disponible.
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
A9N1P03C | SCHNEIDER ELECTRIC | Acti9 xC60 Miniature Circuit Breaker, 1 Pole, 3A, C Curve, 10kA
A9N1P03C | SCHNEIDER ELECTRIC | Acti9 xC60 Miniature Circuit Breake...
A9N1P03C | SCHNEIDER ELECTRIC | Acti9 xC60 Miniature Circuit Breaker, 1 Pole, 3A, C Curve, 10kA
está agotado y se enviará tan pronto como vuelva a estar disponible.
Manufacturer Part Number (MPN)
A9N1P03C
Original Equipment Manufacturer
SCHNEIDER ELECTRIC
Descripción
Series
Acti9 xC60
Poles
1‑Pole (Single Pole)
Rated Current (In)
3 A
Tripping Curve
C‑Curve (thermal‑magnetic)
Rated Operational Voltage (Ue)
220‑240 V AC; up to 60 V DC
Breaking Capacity (Icu)
15 kA (IEC 60947‑2); 10 kA (IEC 60898‑1)
Service Breaking Capacity (Ics)
15 kA @ DC; ~7.5 kA @ AC
Magnetic Trip Limit
≈ 8 × In ± 20 %
Rated Insulation Voltage (Ui)
500 V AC
Impulse Withstand Voltage (Uimp)
6 kV
Mounting
35 mm DIN‑rail clip‑on
Terminal Type
Screw‑clamp terminals, reversible line/load
Dimensions (H×W×D)
85 × 18 × 77.5 mm (2 pitches × 9 mm width)
Weight
≈ 0.115 kg
Electrical Durability
≈ 20,000 operations
Operating Temperature
−30 °C to +70 °C
Protection Class
IP20 (front)
Standards & Certifications
IEC 60947‑2, IEC 60898‑1; IS/IEC 60898; Green Premium; RoHS/REACh compliant
