6AV6 647-0AH11-3AX0 | SIEMENS | Basic Mono PN

₹ 10,649.50

₹ 9,025.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6AV6 647-0AH11-3AX0

Original Equipment Manufacturer

SIEMENS

Descripción
Model 6AV6647-0AH11-3AX0
Product Name SIMATIC HMI KP300 Basic mono PN
Display Type 3.6″ FSTN LCD (Monochrome: Black/White)
Display Resolution 240 × 80 pixels
Number of Colors (Backlight) 4 (white, red, green, yellow)
Number of Function Keys 10
Key Types Function keys + Numeric/Alphanumeric keyboard
Interface / Communication PROFINET / Ethernet; no RS232/USB/RS485 on front
Supply Voltage (DC) 24 V DC (Permissible range: 19.2 - 28.8 V DC)
Current Consumption ≈ 0.1 A
Power Consumption (typ.) 3 W
Ambient Operating Temperature 0 to +50 °C (vertical mounting); reduced to +40 °C at tilt
Storage Temperature –20 to +60 °C
Relative Humidity (Operating) Up to 90 % (non-condensing)
Protection Class / Front IP65 (front), rear IP20
Dimensions (W × H × Depth) 165 × 97 × 30 mm
Cut-out / Mounting Panel Cutouts 149 × 82 mm (W × H); Mounting depth ≈ 30 mm
Weight ≈ 0.25 kg (without packaging); ≈ 0.38 kg (with packaging)
