SPARECRUX is NOT an authorized distributor for SICK SENSORS

6068629 | SICK SENSORS | CQF16-06ENOEP1 Capacitive Proximity Sensors

₹ 14,827.41

₹ 12,565.60 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

6068629

Original Equipment Manufacturer

SICK SENSORS

Descripción

Housing Rectangular
Dimensions (W x H x D) 16 mm x 34 mm x 8 mm
Sensing range Sn 0.5 mm ... 6 mm
Installation type

Flush

Non-flush

Switching frequency 10 Hz
Connection type Cable with M8 male connector, 4-pin, 0.3 m 1)
Switching output NPN
Switching output detail NPN
Output function NC
Supply voltage 10 V ... 30 V
Ripple ≤ 10 %
Voltage drop ≤ 1.5 V DC 1)
Current consumption 13 mA 2)
Time delay before availability ≤ 300 ms
Temperature drift (of Sr) ± 20 %
EMC EN 60947-5-2
Continuous current Ia ≤ 100 mA
Cable material PVC
Conductor size 0.14 mm²
