SPARECRUX is NOT an authorized distributor for FESTO

574429 | FESTO | Solenoid Valve VUVG-L18-M52-MT-G14-1P3

₹ 2,946.41

₹ 2,496.96 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

574429

Original Equipment Manufacturer

FESTO

Descripción

Parameter Value
Valve function 5/2-way, monostable
Type of actuation Electric
Valve size 18 mm
Standard nominal flow rate
(standardised to DIN 1343)
1300 l/min
Pneumatic working port G1/4
Operating voltage 24V DC
Operating pressure 0.3 MPa ... 0.8 MPa
3 bar ... 8 bar
Design Piston gate valve
Type of reset Mechanical spring
Approval RCM trademark
c UL us - Recognized (OL)
Degree of protection IP40
IP65
With plug socket Yes
Nominal size 6.9 mm
Exhaust-air function With flow control option
Sealing principle Soft
Mounting position Optional
manual override Detenting
Non-detenting
Covered
Type of piloting Pilot actuated
Pilot air supply Internal
Symbol 00991003
lap Indefinite overlap
Pilot pressure 0.3 MPa ... 0.8 MPa
3 bar ... 8 bar
Switching time off 45 ms
Switching time on 10 ms
Duty cycle 100%
FESTO
