547862 | FESTO | Proximity Sensor SMT-10G-PS-24V-E-2,5Q-OE

₹ 9,168.33

₹ 7,769.77 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

547862

Original Equipment Manufacturer

FESTO

Descripción
Design For C-slot
Standard EN 60947-5-2
Symbol 00991152
Measured Variable Position
Measuring Principle Magneto-resistive
Mounting Position Optional
Type of Mounting Clamped in C-slot
Insertable In the slot lengthwise
Max. Tightening Torque 0.6 Nm
Product Weight 30 g
Housing Colour Black
Material Housing High-alloy stainless steel
Switching Status Indication Yellow LED
Degree of Protection IP65 / IP68
LABS (PWIS) Conformity VDMA24364-B2-L
Electrical Data
Switching Output PNP
Switching Element Function N/O contact
Switch-on Time ≤ 1 ms
Switch-off Time ≤ 1 ms
Max. Switching Frequency 150 Hz
Max. Output Current 100 mA
Max. Switching Capacity (DC) 2.8 W
Voltage Drop ≤ 2 V
Inductive Protective Circuit Adapted to MZ, MY, ME coils
Off-state Current ≤ 0.01 mA
Short Circuit Current Rating Yes
Overload Protection Available
Rated Operational Voltage (DC) 24 V
Operational Voltage Range (DC) 10 V ... 30 V
Residual Ripple 10 %
Reverse Polarity Protection For all electrical connections
Accuracy and Timing
