SPARECRUX is NOT an authorized distributor for FESTO

541259 | FESTO | On/off Valve MS4-EM1-1/4-S

₹ 2,272.86

₹ 1,926.15 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

541259

Original Equipment Manufacturer

FESTO

Descripción

Feature Details
Design Rotary gate valve
Valve Function 3/2-way bistable
Type of Actuation Manual
Piloting Type Direct
Exhaust-Air Function Without flow control
Symbol 00991670
Flow Direction Non-reversible
Operating Pressure 0 ... 1.4 MPa (0 ... 14 bar)
Standard Nominal Flow Rate 2200 l/min
C Value / b Value 9 l/sbar / 0.39
Operating Medium Compressed air (ISO 8573-1:2010 [7:4:4]), Inert gases
Lubricated Operation Possible (must be maintained once started)
Media & Ambient Temp. -10 °C ... 60 °C
Food Suitability See supplementary info
Mounting Type With accessories
Mounting Position Optional
Corrosion Resistance (CRC) 2 – Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Degree of Protection Not specified
Pneumatic Connection Port 1: G1/4Port 2: G1/4Port 3: Not ducted
Product Weight 210 g
Material – Housing Die-cast aluminium
Material – Seals TPE-U(PU)
RoHS Compliance Yes
FESTO

541259 | FESTO | On/off Valve MS4-EM1-1/4-S

₹ 1,926.15
Feature Details
Design Rotary gate valve
Valve Function 3/2-way bistable
Type of Actuation Manual
Piloting Type Direct
Exhaust-Air Function Without flow control
Symbol 00991670
Flow Direction Non-reversible
Operating Pressure 0 ... 1.4 MPa (0 ... 14 bar)
Standard Nominal Flow Rate 2200 l/min
C Value / b Value 9 l/sbar / 0.39
Operating Medium Compressed air (ISO 8573-1:2010 [7:4:4]), Inert gases
Lubricated Operation Possible (must be maintained once started)
Media & Ambient Temp. -10 °C ... 60 °C
Food Suitability See supplementary info
Mounting Type With accessories
Mounting Position Optional
Corrosion Resistance (CRC) 2 – Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Degree of Protection Not specified
Pneumatic Connection Port 1: G1/4Port 2: G1/4Port 3: Not ducted
Product Weight 210 g
Material – Housing Die-cast aluminium
Material – Seals TPE-U(PU)
RoHS Compliance Yes
