5322547 | SICK SENSORS | LL3-TV06 Fiber-optic Sensors

₹ 10,737.06

₹ 9,099.20 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

5322547

Original Equipment Manufacturer

SICK SENSORS

Descripción

Device type Fiber-optic cables
Functional principle Through-beam system, consisting of a sender and a receiver
Fiber-optic head design Threaded sleeve, 90° deflection
Application Heat-resistant (≥100°C)
Compatible fiber-optic amplifiers WLL80, WLL180, GLL170(T), WLL24 Ex
Sensing range max. 3,180 mm (Sensing range of WLL80 at 8 ms)
Minimal object diameter 0.4 mm 1)
Optical fiber
Fiber length 2,000 mm
Bending radius 25 mm
Dynamic flexibility (robotics) No
Outside diameter, optical fiber cable connection 2.2 mm



SICK SENSORS 5322547 LL3-TV06 Fiber-optic Sensors
SICK SENSORS

5322547 | SICK SENSORS | LL3-TV06 Fiber-optic Sensors

₹ 9,099.20
Device type Fiber-optic cables
Functional principle Through-beam system, consisting of a sender and a receiver
Fiber-optic head design Threaded sleeve, 90° deflection
Application Heat-resistant (≥100°C)
Compatible fiber-optic amplifiers WLL80, WLL180, GLL170(T), WLL24 Ex
Sensing range max. 3,180 mm (Sensing range of WLL80 at 8 ms)
Minimal object diameter 0.4 mm 1)
Optical fiber
Fiber length 2,000 mm
Bending radius 25 mm
Dynamic flexibility (robotics) No
Outside diameter, optical fiber cable connection 2.2 mm
