SPARECRUX is NOT an authorized distributor for FESTO

529234 | FESTO | Filter Regulator MS6-LFR-3/8-D7-EUV-AS

₹ 7,091.35

₹ 6,009.62 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

529234

Original Equipment Manufacturer

FESTO

Descripción
Specification Details
Size 6
Series MS
Actuator Lock Rotary knob with detent, can be closed with accessories
Mounting Position Vertical ±5°
Grade of Filtration 40 µm
Condensate Drain Fully automatic, manual non-detenting
Design Filter regulator with pressure gauge
Max. Condensate Volume 38 ml
Controller Function Output pressure constant, with secondary venting
Bowl Guard Integrated as metal bowl
Degree of Condensate Separation >75 %
Symbol 00991587
Pressure Gauge With pressure gauge
Operating Pressure 0.2 MPa ... 1.2 MPa / 2 bar ... 12 bar
Pressure Regulation Range 0.5 bar ... 12 bar
Max. Pressure Hysteresis 0.025 MPa / 0.25 bar / 3.625 psi
Standard Nominal Flow Rate (DIN 1343) 4000 l/min
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:-], Inert gases
Corrosion Resistance Class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Storage Temperature -10 °C ... 60 °C
Suitable for Use with Food See supplementary material information
Air Purity Class at Output Compressed air to ISO 8573-1:2010 [7:4:4]
Media Temperature -10 °C ... 60 °C
Ambient Temperature -10 °C ... 60 °C
Pore Size <40 µm
Product Weight 1087 g
Type of Mounting With accessories
FESTO

529234 | FESTO | Filter Regulator MS6-LFR-3/8-D7-EUV-AS

₹ 6,009.62
Specification Details
Size 6
Series MS
Actuator Lock Rotary knob with detent, can be closed with accessories
Mounting Position Vertical ±5°
Grade of Filtration 40 µm
Condensate Drain Fully automatic, manual non-detenting
Design Filter regulator with pressure gauge
Max. Condensate Volume 38 ml
Controller Function Output pressure constant, with secondary venting
Bowl Guard Integrated as metal bowl
Degree of Condensate Separation >75 %
Symbol 00991587
Pressure Gauge With pressure gauge
Operating Pressure 0.2 MPa ... 1.2 MPa / 2 bar ... 12 bar
Pressure Regulation Range 0.5 bar ... 12 bar
Max. Pressure Hysteresis 0.025 MPa / 0.25 bar / 3.625 psi
Standard Nominal Flow Rate (DIN 1343) 4000 l/min
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:-], Inert gases
Corrosion Resistance Class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Storage Temperature -10 °C ... 60 °C
Suitable for Use with Food See supplementary material information
Air Purity Class at Output Compressed air to ISO 8573-1:2010 [7:4:4]
Media Temperature -10 °C ... 60 °C
Ambient Temperature -10 °C ... 60 °C
Pore Size <40 µm
Product Weight 1087 g
Type of Mounting With accessories
