36487 | FESTO | Bellows Cylinder EB-165-65

₹ 15,422.53

₹ 13,069.94 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

36487

Original Equipment Manufacturer

FESTO

Descripción

Parameter Value
Size 165
Required installation diameter 180 mm
Stroke 65 mm
Max. extended height 115 mm
Max. angle of inclination 20 deg
Max. offset 10 mm
Min. installation height 51 mm
Mode of operation Single-acting
Symbol 00991205
Operating pressure 0 bar ... 8 bar
Operating medium Compressed air to ISO 8573-1:2010 [-:-:4]
Note on operating and pilot medium Lubricated operation not possible
Corrosion resistance class CRC 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -40 °C ... 70 °C
Reset force 200 N
Product weight 1200 g
Type of mounting Via female thread
Pneumatic connection G1/4
Note on materials RoHS-compliant
Material bellows NR/BR
Material housing Steel, Galvanised
FESTO
