2CDS272001R0634 | ABB | Miniature Circuit Breaker - S200M - 2P - 63 A - C

₹ 8,617.01

₹ 7,302.55 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

2CDS272001R0634

Original Equipment Manufacturer

ABB

Descripción
Feature Specification
Product Type Miniature Circuit Breaker (MCB)
Model Number S202M-C63
Number of Poles 2 (Double Pole)
Rated Current (In) 63 A
Tripping Characteristic C (Magnetic tripping between 5–10 times In)
Rated Voltage (Un) 400 V AC (IEC 60898-1), 440 V AC (IEC 60947-2)
Rated Insulation Voltage (Ui) 440 V AC
Rated Short-Circuit Capacity (Icn) 10 kA at 400 V AC (IEC 60898-1)
Rated Ultimate Short-Circuit Breaking Capacity (Icu) 15 kA at 400 V AC (IEC 60947-2)
Rated Impulse Withstand Voltage (Uimp) 4 kV at sea level, 6.2 kV at 2000 m altitude
Dielectric Test Voltage 2 kV for 1 minute (50/60 Hz)
Energy Limiting Class 3
Overvoltage Category III
Pollution Degree 3
Ambient Temperature Range -25°C to +55°C
Mechanical Endurance 20,000 operations
Electrical Endurance 10,000 operations
Terminal Type Screw terminals
Connecting Capacity - Rigid: 0.75–35 mm²- Flexible: 0.75–25 mm²- Stranded: 0.75–25 mm²
Mounting Type DIN Rail (TH35-7.5, TH35-15)
Mounting Position Any
Housing Material Insulation Group II, RAL 7035
Actuator Type Insulation Group II, black, sealable
Contact Position Indication Red (ON), Green (OFF)
Degree of Protection IP20 (IP40 with cover)
Compliance Standards IEC/EN 60898-1, IEC/EN 60947-2, UL 1077, CSA 22.2 No. 235
