285-135 | WAGO | 2‑Conductor 35 mm² Gray Power CAGE CLAMP® Terminal Block (DIN 35 × 15, Lateral Marker Slots)

₹ 4,652.15

₹ 3,942.50 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

285-135

Original Equipment Manufacturer

WAGO

Descripción

Specification Details
Connection technology POWER CAGE CLAMP®
Actuation type Operating tool
Connectable conductor materials Copper
Nominal cross-section 35 mm²
Solid conductor 6 … 35 mm² / AWG 8 … 2
Stranded conductor 6 … 35 mm² / AWG 8 … 2
Fine‑stranded conductor 6 … 35 mm² / AWG 8 … 2
Fine‑stranded with insulated ferrule 6 … 35 mm² / AWG 8 … 2
Fine‑stranded with uninsulated ferrule 6 … 35 mm² / AWG 8 … 2
Width 16 mm / 0.63 inches
Height 86 mm / 3.386 inches
Depth from upper-edge of DIN-rail 63 mm / 2.48 inches
Color Gray
Material group I
Insulation material (main housing) Polyamide (PA66)
Flammability class (UL94) V‑0
Fire load 1.258 MJ
Weight 79.3 g
WAGO

285-135 | WAGO | 2‑Conductor 35 mm² Gray Power CAGE CLAMP® Terminal Block (DIN 35 × 15, Lateral Marker Slots)

₹ 3,942.50
Specification Details
Connection technology POWER CAGE CLAMP®
Actuation type Operating tool
Connectable conductor materials Copper
Nominal cross-section 35 mm²
Solid conductor 6 … 35 mm² / AWG 8 … 2
Stranded conductor 6 … 35 mm² / AWG 8 … 2
Fine‑stranded conductor 6 … 35 mm² / AWG 8 … 2
Fine‑stranded with insulated ferrule 6 … 35 mm² / AWG 8 … 2
Fine‑stranded with uninsulated ferrule 6 … 35 mm² / AWG 8 … 2
Width 16 mm / 0.63 inches
Height 86 mm / 3.386 inches
Depth from upper-edge of DIN-rail 63 mm / 2.48 inches
Color Gray
Material group I
Insulation material (main housing) Polyamide (PA66)
Flammability class (UL94) V‑0
Fire load 1.258 MJ
Weight 79.3 g
