SPARECRUX is NOT an authorized distributor for LAPP GROUP

281404 | LAPP GROUP | Power And Control Cable, 4g2.5, U0/U: 0,6/1 Kv

₹ 685.56

₹ 580.98 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

281404

Original Equipment Manufacturer

LAPP GROUP

Descripción

Specification Details
Brand ÖLFLEX®
Product Type Power and control cable
Weight 158 kg/km
Copper Index 96.000 kg/km
Copper Index (lb) 650.000 lb/10,000 ft
Test Voltage 2 kV
Current Rating According To IEC 60364-5-52
Max. Conductor Resistance at 20°C 7.98 Ω/km
Cable Dimension 4G2.5
Conductor Cross-Section (mm²) 2.5 mm²
Nominal Cross Section Conductor (AWG) 14 AWG
Conductor Material Bare Copper
Conductor Design IEC 60228 class 5: fine-wire
Nominal Core Diameter 3.05 mm
Min. Outer Diameter 9.16 mm
Nominal Outer Diameter 9.8 mm
Max. Outer Diameter 10.44 mm
Shape of Cable Round
Core Insulation Base Material Polyvinylchloride
Core Insulation Base Material (Short Name) PVC
Insulation Skin Nylon
Base Material of Outer Sheath Thermoplastic
Cable Insulation Colour Grey
Core Identification NumbersLAPP
Wire Per Meter
LAPP GROUP

281404 | LAPP GROUP | Power And Control Cable, 4g2.5, U0/U: 0,6/1 Kv

₹ 580.98
Specification Details
Brand ÖLFLEX®
Product Type Power and control cable
Weight 158 kg/km
Copper Index 96.000 kg/km
Copper Index (lb) 650.000 lb/10,000 ft
Test Voltage 2 kV
Current Rating According To IEC 60364-5-52
Max. Conductor Resistance at 20°C 7.98 Ω/km
Cable Dimension 4G2.5
Conductor Cross-Section (mm²) 2.5 mm²
Nominal Cross Section Conductor (AWG) 14 AWG
Conductor Material Bare Copper
Conductor Design IEC 60228 class 5: fine-wire
Nominal Core Diameter 3.05 mm
Min. Outer Diameter 9.16 mm
Nominal Outer Diameter 9.8 mm
Max. Outer Diameter 10.44 mm
Shape of Cable Round
Core Insulation Base Material Polyvinylchloride
Core Insulation Base Material (Short Name) PVC
Insulation Skin Nylon
Base Material of Outer Sheath Thermoplastic
Cable Insulation Colour Grey
Core Identification NumbersLAPP
Wire Per Meter
