262590 | EATON | Residual-Current Circuit Breaker Trip Block for PLS 63A 4P 30mA Type AC

Name: 262590 | EATON | Residual-Current Circuit Breaker Trip Block for PLS 63A 4P 30mA Type AC
Brand: EATON
Price: 7380.00 INR
Availability: InStock

₹ 8,708.40

₹ 7,380.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Manufacturer Part Number (MPN)

262590

Original Equipment Manufacturer

EATON

Descripción

Manufacturer	Eaton / Eaton Moeller
Series	PBSM (Add-on Residual Current Protection Unit)
Model / Part Number	PBSM-634/003-MW
Alternate Catalog Number	262590
Rated Current (In)	63 A
Number of Poles	4-pole
Residual Fault Current (IΔn)	30 mA (0.03 A)
Type / Sensitivity	Type AC (AC-sensitive residual current device)
Rated Impulse Withstand Voltage (Uimp)	4 kV
Rated Insulation Voltage (Ui)	440 V
Operating Ambient Temperature Range	-25 °C to +40 °C
Mounting Width	125 mm (4 TE) / approx 45 mm front dimension
Degree of Protection	IP40 (standard) / IP54 (with moisture-proof enclosure)
