SPARECRUX is NOT an authorized distributor for FESTO

196032 | FESTO | Round Cylinder DSNU-40-50-PPV-A

₹ 5,271.30

₹ 4,467.20 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

196032

Original Equipment Manufacturer

FESTO

Descripción
Feature Specification
Stroke 50 mm
Piston diameter 40 mm
Piston rod thread M12x1.25
Cushioning Pneumatic cushioning, adjustable at both ends
Mounting position Optional
Design Piston, Piston rod, Cylinder barrel
Position detection Via proximity switch
Symbol 00991235
Operating pressure 0.1 MPa – 1 MPa / 1 bar – 10 bar
Mode of operation Double-acting
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating medium Lubricated operation possible (must always be lubricated if started)
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -20 °C to 80 °C
Impact energy in end positions 0.7 J
Cushioning length 18 mm
Theoretical force at 6 bar (advance stroke) 752.9 N
Theoretical force at 6 bar (return stroke) 633.3 N
Moving mass 310 g
Product weight 781 g
Type of mounting With accessories
Pneumatic connection G1/4
RoHS-compliant Yes
Material cover Wrought aluminium alloy
Material seals NBR, TPE-U(PU)
Material piston rod High-alloy steel
Material cylinder barrel High-alloy stainless steel
