194E-A40-1753-6N | ALLEN BRADLEY | 40A Load Switch, Open - Base/DIN Rail, OFF-ON 90°, 3 Poles, Supplied with a Type N Red/Yellow Actuator
₹ 6,403.48
₹ 5,426.68 (Excl. Tax)
194E-A40-1753-6N | ALLEN BRADLEY | 40A Load Switch, Open - Base/DIN Rail, OFF-ON 90°, 3 Poles, Supplied with a Type N Red/Yellow Actuator
está agotado y se enviará tan pronto como vuelva a estar disponible.
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
194E-A40-1753-6N | ALLEN BRADLEY | 40A Load Switch, Open - Base/DIN Rail, OFF-ON 90°, 3 Poles, Supplied with a Type N Red/Yellow Actuator
194E-A40-1753-6N | ALLEN BRADLEY | 40A Load Switch, Open - Base/DIN Rail, OFF-ON 90°, 3 Poles, Supplied with a Type N Red/Yellow Actuator
está agotado y se enviará tan pronto como vuelva a estar disponible.
Manufacturer Part Number (MPN)
194E-A40-1753-6N
Original Equipment Manufacturer
ALLEN BRADLEY
Descripción
Attribute
Value
Product Type
IEC Load Switch with Type N Red/Yellow Actuator
Rated Current (Iu)
40 A
Number of Poles
3
Configuration
OFF-ON 90°
Mounting Style
Base/DIN Rail
Actuator Type
Type N Red/Yellow Actuator
Rated Operational Voltage (Ue)
690V AC
Rated Insulation Voltage (Ui)
690V AC
Rated Frequency
50/60 Hz
Conventional Free Air Thermal Current (Ith)
63 A
Conventional Enclosed Thermal Current (Ie)
50 A
Short-Circuit Current (Coordination Type 2)
50 A @ 400/415V
Rated Breaking Capacity AC-23A (cosφ 0.45)
504 A @ 400V
Motor Rating (UL/CSA)
30.4 A @ 120V, 60 Hz, 3-phase; 7.5 Hp @ 600V, 60 Hz, 1-phase
Power Loss per Pole
1.6 W
Switching Rate
120 operations/hour
Protection Class (Switch Body)
IP20
Mechanical Life
0.2 million operations
Standards Compliance
IEC 60947-3, UL 508, CSA C22.2 No. 14
