SPARECRUX is NOT an authorized distributor for FESTO

This product has been discontinued, and manufacturer warranty or support may no longer be available.

192599 | FESTO | Filter Regulator LFR-1-D-7-O-MAXI

₹ 13,595.41

₹ 11,521.53 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

192599

Original Equipment Manufacturer

FESTO

Descripción

Parameter Value
Size Maxi
Series D
Actuator lock Rotary knob with detent
Mounting position Vertical ±5°
Grade of filtration 40 µm
Condensate drain Manually rotating
Design Filter regulator without pressure gauge
Max. condensate volume 80 ml
Bowl guard Metal bowl guard
Symbol 00991590
Pressure gauge/display Prepared for G1/4
Operating pressure 0.1 MPa ... 1.6 MPa (1 bar ... 16 bar)
Pressure regulation range 0.5 bar ... 7 bar
Max. pressure hysteresis 0.4 bar
Standard nominal flow rate 11000 l/min (DIN 1343)
Operating medium Inert gases
Corrosion resistance class (CRC) 2 - Moderate corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Storage temperature -10 °C ... 60 °C
Air purity class at output Compressed air to ISO 8573-1:2010 [7:8:4], Inert gases
Media temperature -10 °C ... 60 °C
Ambient temperature -10 °C ... 60 °C
Product weight 1470 g
Type of mounting With accessories
Pneumatic connection, port 1 G1
Pneumatic connection, port 2 G1
Note on materials RoHS-compliant
Material housing Die-cast zinc
Material bowl PC
FESTO
