SPARECRUX is NOT an authorized distributor for FESTO

19194 | FESTO | ISO Cylinder DSNU-12-100-P-A

₹ 2,450.73

₹ 2,076.89 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

19194

Original Equipment Manufacturer

FESTO

Descripción
Specification Details
Stroke 100 mm
Piston Diameter 12 mm
Piston Rod Thread M6
Cushioning Elastic cushioning rings/plates at both ends
Mounting Position Optional
Standard Compliance ISO 6432
Piston-Rod End Male thread
Design Piston, Piston rod, Cylinder barrel
Position Detection Via proximity switch
Symbol 00991217
Variants Piston rod at one end
Operating Pressure 0.15 MPa – 1 MPa (1.5 – 10 bar)
Mode of Operation Double-acting
Operating Medium Compressed air (ISO 8573-1:2010 [7:4:4])
Pilot Medium Note Lubricated operation possible (if started lubricated, must continue lubricated)
Corrosion Resistance Class (CRC) 2 (Moderate corrosion stress)
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Cleanroom Class ISO Class 6 (ISO 14644-1)
Ambient Temperature Range -20 °C to +80 °C
Impact Energy (End Positions) 0.07 J
Theoretical Force @ 0.6 MPa (6 bar) Return Stroke: 50.9 NAdvance Stroke: 67.9 N
Moving Mass (0 mm Stroke) 18.5 g
Additional Moving Mass per 10 mm Stroke 2 g
Basic Weight (0 mm Stroke) 75 g
Additional Weight per 10 mm Stroke 4 g
Mounting Type With accessories
Pneumatic Connection M5
RoHS Compliance Yes
Material - Cover Wrought aluminium alloy (Colourless anodised)
Material - Seals NBR, TPE-U(PU)
Material - Piston Rod High-alloy stainless steel
Material - Cylinder Barrel High-alloy stainless steel
