SPARECRUX is NOT an authorized distributor for FESTO

190661 | FESTO | Push-in L-fitting QSL-1/2-10

₹ 396.93

₹ 336.38 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

190661

Original Equipment Manufacturer

FESTO

Descripción
Feature Specification
Size Standard
Nominal Size 8.3 mm
Type of Seal on Screwed Plug Coating
Mounting Position Optional
Design L-shape, Push-pull principle
Pack Size 1
Operating Pressure (Complete Temp Range) -0.095 MPa ... 0.6 MPa -0.95 bar ... 6 bar -13.775 psi ... 87 psi
Temperature-dependent Operating Pressure -0.095 MPa ... 1.4 MPa -0.95 bar ... 14 bar -13.775 psi ... 203 psi
Note on Operating Pressure Water: max. 0.6 MPa at max. 50°C
Operating Medium Compressed air (ISO 8573-1:2010 [7:-:-]), Water (liquid, ice-free)
Lubrication Note Lubricated operation possible
Corrosion Resistance Class (CRC) 1 – Low corrosion stress
LABS (PWIS) Conformity VDMA24364-B1/B2-L
Cleanroom Class Class 4 (ISO 14644-1)
Ambient Temperature Range -10 °C to 80 °C
Nominal Torque 26 Nm
Torque Tolerance ± 20%
Product Weight 57 g
Mounting Type External hexagon, size 21 mm
Pneumatic Connection – Port 1 Male thread R1/2
Pneumatic Connection – Port 2 For tubing outside diameter of 10 mm
Colour of Release Ring Blue
Material – Screwed Plug Nickel-plated brass
