186227 | FESTO | Multiple Distributor QSLV2-G1/4-8

₹ 779.24

₹ 660.37 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

186227

Original Equipment Manufacturer

FESTO

Descripción
Feature Specification
Size Standard
Nominal size 4.3 mm
Type of seal on screwed plug Sealing ring
Mounting position Optional
Design Push-pull principle
Size of pack 1
Operating pressure (complete range) -0.095 MPa ... 0.6 MPa
Operating pressure (bar) -0.95 bar ... 6 bar
Operating pressure (psi) -13.775 psi ... 87 psi
Temperature-dependent operating pressure -0.095 MPa ... 1.4 MPa
Temperature-dependent operating pressure (bar) -0.95 bar ... 14 bar
Temperature-dependent operating pressure (psi) -13.775 psi ... 203 psi
Note on operating pressure Water: max. 0.6 MPa at 0 - 50 °C
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-], Water (liquid, ice-free)
Note on operating and pilot medium Lubricated operation possible; Water: G-thread only possible with sealing ring type OL as additional accessory
Corrosion resistance class CRC 1 - Low corrosion stress
LABS (PWIS) conformity VDMA24364-B1/B2-L
Ambient temperature -10 °C ... 80 °C
Nominal torque 9 Nm
Tolerance for nominal tightening torque ± 20%
Product weight 44 g
Number of outputs 2
Number of supply lines 1
Pneumatic connection, port 1 Male thread G1/4
Pneumatic connection, port 2 For tubing outside diameter of 8 mm
Colour of release ring Blue
Note on materials RoHS-compliant
