1788100000| WEIDMULLER | HDC Enclosures Size 3 Protection Degree IP65

₹ 568.29

₹ 481.60 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1788100000

Original Equipment Manufacturer

WEIDMULLER

Descripción

Parameter Specification
Type / Series HDC 06B TSLU 1M20G
GTIN (EAN) 4032248205547
Shell Size 3
Material Die-cast aluminum
Cable Entry M20, side entry
Locking Mechanism End-locking clamp (lower side)
Ingress Protection IP65 (in plugged condition)
Operating Temp. Range –40°C to +125°C
Mounting Orientation Angled
Insert Mounting Dimensions 44 x 27 mm
Dimensions (L x W x H) 60 mm x 43 mm x 52 mm
Weight 120 g
Surface Finish Powder coating
Housing Color (RAL) RAL 7035 (light grey)
Locking Element Material Stainless steel, rust-proof
Tightening Torque 1.2 Nm
Flammability Rating UL94 V-0
WEIDMULLER
