SPARECRUX is NOT an authorized distributor for FESTO

178413 | FESTO | Plastic Tubing PUN-10X1,5-RT

₹ 293.70

₹ 248.90 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

178413

Original Equipment Manufacturer

FESTO

Descripción

Property Value
Outside diameter 10 mm
Inside diameter 7 mm
Flow-relevant bending radius 54 mm
Min. bending radius 28 mm
Instructions on use TPE-U Ester based. The plastic tubing can only be installed in contact with cables if the sheathing is free of phosphoric acid esters. Otherwise the plastic tubing may get damaged.
Tubing characteristics Suitable for energy chains
Operating pressure (complete temperature range) -0.095 MPa ... 0.7 MPa
Operating pressure (complete temperature range) -0.95 bar ... 7 bar
Operating pressure (complete temperature range) -13.775 psi ... 101.5 psi
Temperature-dependent operating pressure -0.095 MPa ... 1 MPa
Temperature-dependent operating pressure -0.95 bar ... 10 bar
Temperature-dependent operating pressure -13.775 psi ... 145 psi
Approval German Technical Control Board (TÜV)
Certificate issuing authority B 013277 0506 00
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
Fire test material UL94 HB
LABS (PWIS) conformity VDMA24364-B2-L
Ambient temperature -35 °C ... 60 °C
Product weight according to length 0.0489 kg/m
Pneumatic connection For push-in connector O.D. 10 mm
Colour Red
Shore hardness D 52 +/-3
Note on materials RoHS-compliant
Wire price Per meter
