SPARECRUX is NOT an authorized distributor for FESTO
175404 | FESTO | Proximity Sensor SME-8-K5-LED-24
₹ 2,344.12
₹ 1,986.54 (Excl. Tax)
No se ha podido cargar la disponibilidad de recogida
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
RCM trademark, CE mark (see declaration of conformity), To EU EMC Directive, In accordance with EU RoHS Directive, UKCA marking (see declaration of conformity), To UK instructions for EMC, To UK RoHS instructions
Note on materials
RoHS-compliant
Instructions on use
Support / actuator-sensor overview "The right sensor for the actuator"
Measured variable
Position
Measuring principle
Magnetic reed
Ambient temperature
-40 °C ... 70 °C
Repetition accuracy
0.2 mm
Switching output
Contacting, bipolar
Switching element function
N/O contact
Switch-on time
≤0.5 ms
Switch-off time
0.03 ms
Max. switching frequency
800 Hz
Max. output current
500 mA
Max. switching capacity AC
10 VA
Max. switching capacity DC
10 W
Voltage drop
0 V
Inductive protective circuit
Adapted to MZ, MY, ME coils
Short circuit current rating
no
Overload protection
Not available
Operational voltage range AC
12 V ... 30 V
Operational voltage range DC
12 V ... 30 V
Reverse polarity protection
no
Electrical connection 1, connection type
Cable
Electrical connection 1, connector system
Open end
Electrical connection 1, number of connections/cores
3
Connection outlet orientation
In-line
Cable length
5 m
Cable sheath colour
Grey
Material cable sheath
TPE-U(PUR)
Type of mounting
Clamped in T-slot, Insertable in the slot lengthwise
Tightening torque
0.2 Nm
Mounting position
optional
Product weight
60 g
Housing colour
Black
Material housing
PC, PET, High-alloy stainless steel
Switching status indication
Yellow LED
Ambient temperature with moving cable
-5 °C ... 70 °C
Degree of protection
IP65, IP67
Insulation voltage
50 V
Immunity to surge
0.8 kV
LABS (PWIS) conformity
VDMA24364-B2-L
Pollution degree
3
