175250 | FESTO | Pressure Switch PEV-1/4-B-OD

₹ 8,642.21

₹ 7,323.91 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

175250

Original Equipment Manufacturer

FESTO

Descripción
Feature Specification
Conforms to standard EN 60947-5-1
Symbol 00991471
Approval CCC, CE mark (see declaration of conformity), UKCA marking (see declaration of conformity)
Explosion protection Zone 1 (ATEX), Zone 2 (ATEX), Zone 21 (ATEX), Zone 22 (ATEX) (The information in the certificate must be observed!)
Note on materials RoHS-compliant
Measured variable Relative pressure
Measurement method Pneumatic/electric pressure transducer
Operating pressure 0.1 MPa ... 1.2 MPa (1 bar ... 12 bar)
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-], Water
Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
Media temperature -20 °C ... 80 °C
Ambient temperature -20 °C ... 80 °C
Switching element function Changeover switch
Max. switching frequency 3 Hz
Max. switching output voltage AC 250 V
Max. switching output voltage DC 125 V
Max. output current 5000 mA
Min. load current 1 mA at 24 V, 10 mA at 10 V, 100 mA at 5 V
Utilisation category - inductive load AC-14, DC-13
Utilisation category - resistive load AC-12, DC-12
Electrical connection Type A, Plugs, To DIN 43650, Square design
Type of mounting With through-hole
Mounting position Optional
Pneumatic connection G1/4
Product weight 194 g
Material housing Die-cast aluminium
Material switch contact Silver
Switching status indication Yellow LED
Setting range threshold value 1 bar ... 12 bar
Degree of protection IP65
Corrosion resistance class CRC 2 - Moderate corrosion stress
