SPARECRUX is NOT an authorized distributor for FESTO

171157 | FESTO | Plug Socket MSSD-C-4P

₹ 190.29

₹ 161.26 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

Original Equipment Manufacturer

FESTO

Descripción

Property Specification
Type of Mounting On solenoid valve via M3 central screw
Mounting Position Optional
Product Weight 22 g
Electrical Connection 3-pin, Angled socket
Connector Type Type A
Standard DIN EN 175301-803
Design Compatibility Square design MSC / MSN1
Cable Fitting Pg 9
Cable Diameter 6 mm ... 8 mm
Nominal Cross Section Conductor ≤ 1.5 mm²
Degree of Protection IP65
Ambient Temperature -25 °C ... 90 °C
LABS (PWIS) Conformity VDMA24364-B2-L
Note on Materials RoHS-compliant
Material (Housing) Polymer
Housing Colour Black
