1652470000| WEIDMULLER | HDC Enclosures Size 1 Protection Degree IP65

₹ 409.70

₹ 347.20 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1652470000

Original Equipment Manufacturer

WEIDMULLER

Descripción

Parameter Specification
Type / Series HDC 04A TOLU 1PG11G – Cable‑entry from top, plug housing
GTIN (EAN) 400 819 040 2549
Shell Size 1 (also called 04A)
Housing Material Die‑cast aluminium, powder‑coated
Cable Entry PG 11, cable entry from top
Locking Mechanism Side‑locking clamp on lower side
Ingress Protection IP65 (in plugged state)
Ambient Temperature Range –40 °C to +125 °C
Depth 26.8 mm (1.055 in)
Height 50 mm (1.969 in)
Width 36.5 mm (1.437 in)
Mounting Dimension (width) 26.8 mm
Net Weight ≈ 27 g
Surface Finish Powder coating
Housing Colour (RAL) RAL 7035 (light grey)
Tightening Torque 0.5 Nm
Suitable for ModuPlug® No
Flammability Rating UL 94 V‑0 (cable-entry gland only)
Approvals & Compliance RoHS compliant (exemption 6bI), REACH SVHC: Lead 7439‑92‑1; cURus
