161416 | FESTO | Solenoid Valve CPV10-M1H-2X3-GLS-M7

₹ 7,130.85

₹ 6,043.09 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

161416

Original Equipment Manufacturer

FESTO

Descripción

Parameter Specification
Valve function 2x3/2-way, monostable, closed
Type of actuation Electric
Valve size 10 mm
Standard nominal flow rate 400 l/min (DIN 1343)
Pneumatic working port M7
Operating voltage 24V DC
Operating pressure -0.09 MPa ... 1 MPa (-0.9 bar ... 10 bar)
Design Piston gate valve
Nominal size 4 mm
Exhaust-air function Without flow control option
Sealing principle Soft
Mounting position Optional
Manual override Detenting / Non-detenting
Type of piloting Pilot actuated
Pilot air supply External / Internal
Flow direction Non-reversible
Symbol 00991808
Overlap (lap) Yes
Pilot pressure 0.3 MPa ... 0.8 MPa (3 bar ... 8 bar)
b value 0.4
C value 1.6 l/sbar
Switching time off 25 ms
Switching time on 17 ms
Duty cycle 100% (with holding current reduction)
Electrical power consumption 0.46 W
Max positive test pulse (0 signal) 1400 µs
Max negative test pulse (1 signal) 700 µs
Product weight 70 g
Type of mounting With through-hole
