152584 | FESTO | Plastic Tubing PUN-4X0,75-SI
está agotado y se enviará tan pronto como vuelva a estar disponible.
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
152584 | FESTO | Plastic Tubing PUN-4X0,75-SI
está agotado y se enviará tan pronto como vuelva a estar disponible.
Manufacturer Part Number (MPN)
152584
Original Equipment Manufacturer
FESTO
Descripción
Specification
Details
Outside diameter
4 mm
Flow-relevant bending radius
17 mm
Inside diameter
2.6 mm
Min. bending radius
8 mm
Instructions on use
TPE-U Ester based. The plastic tubing can only be installed in contact with cables if the sheathing is free of phosphoric acid esters. Otherwise, the plastic tubing may get damaged.
Tubing characteristics
Suitable for energy chains
Operating pressure complete temperature range
-0.095 MPa ... 0.7 MPa -0.95 bar ... 7 bar -13.775 psi ... 101.5 psi
Temperature-dependent operating pressure
-0.095 MPa ... 1 MPa -0.95 bar ... 10 bar -13.775 psi ... 145 psi
Approval
German Technical Control Board (TÜV)
Certificate issuing authority
B 013277 0506 00
Operating medium
Compressed air to ISO 8573-1:2010 [7:-:-]
Fire test material
UL94 HB
LABS (PWIS) conformity
VDMA24364-B2-L
Ambient temperature
-35 °C ... 60 °C
Product weight according to length
0.0089 kg/m
Pneumatic connection
For push-in connector O.D. 4 mm For barbed fitting I.D. 3 mm with union nut For barbed fitting I.D. 3 mm
Colour
Silver
Shore hardness
D 52 +/-3
Note on materials
RoHS-compliant
Material tubing
TPE-U(PU)
Wire price
Per meter
