14124 | FESTO | ISO Cylinder DNU-32-80-PPV-A

₹ 1,011.71

₹ 857.38 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

14124

Original Equipment Manufacturer

FESTO

Descripción
Feature Specification
Model DNU-32-80-PPV-A (14124)
Cylinder Type ISO Cylinder (DNU series)
Nominal Bore Size 32 mm
Stroke Length 80 mm
Mounting Type Pneumatic connection with male thread (M5)
Cushioning Pneumatic cushioning at both ends
Operating Pressure 0.06 MPa to 1.2 MPa (0.6 bar to 12 bar)
Operating Medium Compressed air to ISO 8573-1:2010 [7:4:4]
Ambient Temperature Range -20 °C to 70 °C
Corrosion Resistance Class CRC 2 – Moderate corrosion stress
LABS (PWIS) Conformity VDMA24364-B2-L
Position Detection Via proximity switch
Piston Rod Thread M12x1.5
Cylinder Design Piston rod with profile barrel
Materials Housing: Die-cast aluminium (coated)
Piston rod: High-alloy steel
Seals: TPE-U(PU)
Weight 0.74 kg (basic weight for 0 mm stroke)
Additional Weight per 10 mm Stroke 73 g
Additional Moving Mass per 10 mm Stroke 25 g
Theoretical Force at 0.6 MPa (Advance Stroke) 1870 N
Theoretical Force at 0.6 MPa (Return Stroke) 1682 N
Impact Energy in End Positions 0.5 J
Cushioning Length 22 mm
Max Tightening Torque 1.5 Nm
Pneumatic Connection G1/8
