190646 | FESTO | Push-in Fitting QS-1/2-10

₹ 240.02

₹ 203.41 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

190646

Original Equipment Manufacturer

FESTO

Descripción

Parameter Specification
Size Standard
Nominal size 9 mm
Type of seal on screwed plug Coating
Mounting position Optional
Design Straight design
Size of pack 1
Design (principle) Push-pull principle
Operating pressure complete temperature range -0.095 MPa ... 0.6 MPa
-0.95 bar ... 6 bar
-13.775 psi ... 87 psi
Nominal torque 26 Nm
Tolerance for nominal tightening torque ± 20%
Product weight 46 g
Type of mounting External hexagon, size 21 mm
Pneumatic connection, port 1 Male thread R1/2
Pneumatic connection, port 2 For tubing outside diameter of 10 mm
Colour of release ring Blue
Note on materials RoHS-compliant
Material housing Brass, nickel-plated
