1108739 | SICK SENSORS | IMM04-0B6PSVR8S Inductive Proximity Sensor

₹ 4,303.22

₹ 3,646.80 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Housing Metric
Housing Standard design
Thread size M4 x 0.5
Diameter Ø 4 mm
Sensing range Sn 0.6 mm
Safe sensing range Sa 0.486 mm
Installation type Flush
Switching frequency 5,000 Hz
Connection type Cable with connector M8, 3-pin, 0.2 m
Switching output PNP
Switching output detail PNP
Output function NO
Electrical wiring DC 3-wire
Enclosure rating IP67 1)
Supply voltage 10 V DC ... 30 V DC
Ripple ≤ 20 % 1)
Voltage drop ≤ 2 V 2)
Time delay before availability ≤ 10 ms
Hysteresis 1 % ... 15 %
Reproducibility ≤ 2.5 % 3)
Temperature drift (of Sr) ≤ 10 %
EMC EN 60947-5-2
Continuous current Ia ≤ 100 mA
Cable material PUR
Cable diameter Ø 2.5 mm
Short-circuit protection ✔
Power-up pulse protection ✔
Shock and vibration resistance 30 g, 11 ms / 10 ... 55 Hz, 1 mm
Ambient operating temperature –25 °C ... +70 °C
Housing material Stainless steel V2A, DIN 1.4305 / AISI 303
Sensing face material Plastic, LCP
Housing length 22 mm
Thread length 20 mm
Tightening torque, max. ≤ 0.8 Nm
Housing material Stainless steel V2A, DIN 1.4305 / AISI 303
Sensing face material Plastic, LCP
Housing length 22 mm
Thread length 20 mm
Tightening torque, max. ≤ 0.8 Nm

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1108739

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Housing - Metric

Housing - Standard design

Thread size - M4 x 0.5

Diameter - Ø 4 mm

Sensing range Sn - 0.6 mm

Safe sensing range Sa - 0.486 mm

Installation type - Flush

Switching frequency - 5,000 Hz

Connection type - Cable with connector M8, 3-pin, 0.2 m

Switching output - PNP

Switching output detail - PNP

Supply voltage - 10 V DC ... 30 V DC

Ripple - ≤ 20 % 1)

Voltage drop - ≤ 2 V 2)

Time delay before availability - ≤ 10 ms

Hysteresis - 1 % ... 15 %

Reproducibility - ≤ 2.5 % 3)

Temperature drift (of Sr) - ≤ 10 %

EMC - EN 60947-5-2

Continuous current Ia - ≤ 100 mA

Cable material - PUR

MTTFD - 1,638 years

DCavg - 0 %

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

IO-Link certificate - ✔

Note - The values are reference values which may vary

St37 steel (Fe) - 1

Stainless steel (V2A, 304) - Approx. 0.68

Aluminum (Al) - Approx. 0.51

Copper (Cu) - Approx. 0.38

Brass (Br) - Approx. 0.64
