1108738 | SICK SENSORS | IMM04-01BPSVR8K Inductive Proximity Sensor

₹ 4,619.70

₹ 3,915.00 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Housing Metric
Housing Short-body
Thread size M4 x 0.5
Diameter Ø 4 mm
Sensing range Sn 1 mm
Safe sensing range Sa 0.81 mm
Installation type Flush
Switching frequency 4,200 Hz
Connection type Cable with connector M8, 3-pin, 0.2 m
Switching output PNP
Switching output detail PNP
Output function NO
Electrical wiring DC 3-wire
Enclosure rating IP67 1)
Housing length 12 mm
Thread length 10 mm
Tightening torque, max. ≤ 0.8 Nm



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1108738

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Housing - Metric

Housing - Short-body

Thread size - M4 x 0.5

Diameter - Ø 4 mm

Sensing range Sn - 1 mm

Safe sensing range Sa - 0.81 mm

Installation type - Flush

Switching frequency - 4,200 Hz

Connection type - Cable with connector M8, 3-pin, 0.2 m

Switching output - PNP

Switching output detail - PNP

Output function - NO

Electrical wiring - DC 3-wire

Supply voltage - 10 V DC ... 30 V DC

Ripple - ≤ 20 % 1)

Voltage drop - ≤ 2 V 2)

Time delay before availability - ≤ 10 ms

Hysteresis - 1 % ... 15 %

Reproducibility - ≤ 2.5 % 3)

Temperature drift (of Sr) - ≤ 10 %

EMC - EN 60947-5-2

Continuous current Ia - ≤ 100 mA

Cable material - PUR

Cable diameter - Ø 2.5 mm

Short-circuit protection - ✔

Power-up pulse protection - ✔

MTTFD - 1,804 years

DCavg - 0 %

EU declaration of conformity - ✔

UK declaration of conformity - ✔

ACMA declaration of conformity - ✔

Moroccan declaration of conformity - ✔

China RoHS - ✔

cULus certificate - ✔

IO-Link certificate - ✔

Note - The values are reference values which may vary

St37 steel (Fe) - 1

Stainless steel (V2A, 304) - Approx. 0.7

Aluminum (Al) - Approx. 0.49

Copper (Cu) - Approx. 0.4

Brass (Br) - Approx. 0.55
