1101164 | SICK SENSORS | IHM06-02BPSVW2K Inductive Proximity Sensor

₹ 3,289.01

₹ 2,787.30 (Excl. Tax)

Get Best Price on WhatsApp

Product Description
Housing Cylindrical
Housing Short-body
Diameter Ø 6.5 mm
Sensing range Sn 2 mm
Safe sensing range Sa 1.62 mm
Installation type Flush
Switching frequency 5,000 Hz
Connection type Cable, 3-wire, 2 m
Switching output PNP
Switching output detail PNP
Output function NO
Electrical wiring DC 3-wire
Housing material Stainless steel V2A, DIN 1.4305 / AISI 303
Sensing face material Plastic, LCP
Housing length 31.3 mm



Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

SPARECRUX is NOT an authorized distributor for SICK SENSORS

Manufacturer Part Number (MPN)

1101164

Original Equipment Manufacturer

SICK SENSORS

PDF Product Datasheet

  • 100% Tested & Verified Products

  • GST Invoice Available

  • Warranty Included

  • Trusted by 5000+ Industrial Buyers

Housing - Cylindrical

Housing Type - Short-body

Diameter - Ø 6.5 mm

Sensing Range (Sn) - 2 mm

Safe Sensing Range (Sa) - 1.62 mm

Installation Type - Flush

Switching Frequency - 5,000 Hz

Connection Type - Cable, 3-wire, 2 m

Switching Output - PNP

Switching Output Detail - PNP

Output Function - NO (Normally Open)

Supply Voltage - 10 V DC ... 30 V DC

Ripple - ≤ 20 % ¹

Voltage Drop - ≤ 2 V ²

Time Delay Before Availability - ≤ 50 ms

Hysteresis - 1 % ... 10 %

Reproducibility - ≤ 2 % ³

Temperature Drift (of Sr) - ≤ 10 %

EMC - EN 60947-5-2

Continuous Current (Ia) - ≤ 200 mA

Cable Material - PVC

Conductor Size - 0.25 mm²

Cable Diameter - Ø 3.7 mm

MTTFD - 1,330 years

DCavg - 0 %

EU Declaration of Conformity - ✔

UK Declaration of Conformity - ✔

ACMA Declaration of Conformity - ✔

Moroccan Declaration of Conformity - ✔

China RoHS - ✔

cULus Certificate - ✔

IO-Link Certificate - ✔

Information According to Art. 3 of Data Act (Regulation EU 2023/2854) - ✔

Note - The values are reference values and may vary.

St37 Steel (Fe) - 1

Stainless Steel (V2A, 304) - Approx. 0.75

Aluminum (Al) - Approx. 0.5

Copper (Cu) - Approx. 0.43

Brass (Br) - Approx. 0.54
