SPARECRUX is NOT an authorized distributor for SICK SENSORS

1072569 | SICK SENSORS | IME08-06NNSZC0S Inductive Proximity Sensor

₹ 6,488.11

₹ 5,498.40 (Excl. Tax)


  Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1072569

Original Equipment Manufacturer

SICK SENSORS

Descripción

Housing Metric
Housing Standard design
Thread size M8 x 1
Diameter Ø 8 mm
Sensing range Sn 6 mm
Safe sensing range Sa 4.86 mm
Installation type Non-flush
Switching frequency 500 Hz
Connection type Male connector M12, 4-pin
Switching output NPN
Switching output detail NPN
Output function NO
Electrical wiring DC 3-wire
Enclosure rating IP67 1)
Housing material Brass, nickel-plated
Sensing face material Plastic, PA 66
Housing length 52 mm
Thread length 23 mm
Tightening torque, max. ≤ 5 Nm



SICK SENSORS 1072569 IME08-06NNSZC0S Inductive Proximity Sensor
