1062960 | SICK SENSORS | PAC50-BGC Pressure Sensor

₹ 16,179.22

₹ 13,711.20 (Excl. Tax)

●   Available for backorder, with an estimated lead time of 8 to 12 weeks.

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1062960

Original Equipment Manufacturer

SICK SENSORS

Descripción
Medium Dry compressed air
Pressure type Gauge pressure
Pressure unit bar
Measuring range –1 bar ... 1 bar
Overpressure safety 5 bar
Process temperature 0 °C ... +60 °C
Maximum ohmic load RA Optional, 4 mA ... 20 mA / 0 V… 10 V. Automatic detection depending on connected load or programmable. Output signals can be inverted: 20 mA ... 4 mA / 10 V ... 0 V, Load resistance for current output < 600 Ohm, Load resistance with current output > 3 kOhm
Zero point adjustment Max. + 5 % of span
Communication interface -
Process connection 2 x G ¼ 1)
Housing material Housing: polycarbonate, Buttons: TPE, DIN rail mounting: POM, seals: NBR
Connection type Round connector M12 x 1, 5-pin
Supply voltage 17 V DC ... 30 V DC
Power consumption Max. 40 mA at L+ = 24 VDC



SICK SENSORS 1062960 PAC50-BGC Pressure Sensor
SICK SENSORS

1062960 | SICK SENSORS | PAC50-BGC Pressure Sensor

₹ 13,711.20
Medium Dry compressed air
Pressure type Gauge pressure
Pressure unit bar
Measuring range –1 bar ... 1 bar
Overpressure safety 5 bar
Process temperature 0 °C ... +60 °C
Maximum ohmic load RA Optional, 4 mA ... 20 mA / 0 V… 10 V. Automatic detection depending on connected load or programmable. Output signals can be inverted: 20 mA ... 4 mA / 10 V ... 0 V, Load resistance for current output < 600 Ohm, Load resistance with current output > 3 kOhm
Zero point adjustment Max. + 5 % of span
Communication interface -
Process connection 2 x G ¼ 1)
Housing material Housing: polycarbonate, Buttons: TPE, DIN rail mounting: POM, seals: NBR
Connection type Round connector M12 x 1, 5-pin
Supply voltage 17 V DC ... 30 V DC
Power consumption Max. 40 mA at L+ = 24 VDC
