SPARECRUX is NOT an authorized distributor for FESTO

10192 | FESTO | Front Panel Valve SVS-4-1/8

₹ 10,556.86

₹ 8,946.49 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

10192

Original Equipment Manufacturer

FESTO

Descripción
Parameter Value
Valve function 4/2-way, monostable
Type of actuation Mechanical
Standard nominal flow rate (DIN 1343) 120 l/min
Pneumatic working port G1/8
Operating pressure 0.35 MPa ... 0.8 MPa
Operating pressure 3.5 bar ... 8 bar
Design Piston seat
Type of reset Mechanical spring
Sealing principle Soft
Actuating force 8 N
Type of mounting With through-hole
Pneumatic connection, port 1 G1/8
Pneumatic connection, port 2 G1/8
Pneumatic connection, port 3 G1/8
Pneumatic connection, port 4 G1/8
Material cover POM
Material seals NBR, TPE-U(PU)
Material housing Aluminium
