1734-IB8S | ALLEN BRADLEY | POINT Guard I/O 8-Channel Safety Sinking Input Module
₹ 35,720.44
₹ 30,271.56 (Excl. Tax)
Couldn't load pickup availability
Warranty
Warranty
We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.
Delivery and Shipping
Delivery and Shipping
We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.
Manufacturer Part Number (MPN)
1734-IB8S
Original Equipment Manufacturer
ALLEN BRADLEY
Description
Description
Specification |
Description |
Input Voltage Rating |
24V DC nominal |
Input Voltage Range |
19.2…28.8V DC |
Number of Inputs |
8 safety sinking inputs |
Input Current |
4.5 mA per channel at 24V DC |
Input Delay Time |
Off to On: 0.5 ms; On to Off: 4 ms |
Test Pulse Width |
200 µs |
Test Pulse Interval |
20 ms |
Power Consumption |
2.5 W max |
Power Dissipation |
8.5 BTU/hr max |
Operating Temperature Range |
-20…55 °C (-4…131 °F) |
Storage Temperature Range |
-40…85 °C (-40…185 °F) |
Dimensions (HxWxD) |
56.6 x 12 x 75.5 mm (2.23 x 0.47 x 2.97 in.) |
Certifications |
CE, UL, c-UL, TÜV Rheinland, SIL 3, PLe |
