2095899 | SICK SENSOR | Sensor Actuator Cable

₹ 3,133.01

₹ 2,655.10 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

2095899

Original Equipment Manufacturer

SICK SENSORS

Descripción
Specification Details
Manufacturer SICK
Part Number / Type YF8U14-150VA3XLEAX (2095899)
Product Type Sensor / Actuator Cable
Connector A M8, 4-pin, straight, A-coded, female (plug connector) :contentReference[oaicite:3]{index=3}
Connector B Flying leads / Unterminated free end :contentReference[oaicite:4]{index=4}
Cable Length 5 m (≈ 16.4 ft) :contentReference[oaicite:5]{index=5}
Number of Cores / Wires 4-wire (4 conductors) :contentReference[oaicite:6]{index=6}
Conductor Cross-Section 0.25 mm² :contentReference[oaicite:7]{index=7}
Cable Jacket Material PVC (gray) :contentReference[oaicite:8]{index=8}
Cable Diameter ≈ 4.8 mm :contentReference[oaicite:9]{index=9}
Shielding Unshielded :contentReference[oaicite:10]{index=10}
Max. Operating Voltage 60 V AC / 60 V DC (signal/sensor cable) :contentReference[oaicite:11]{index=11}
Rated Current / Current Loading ≤ 4 A :contentReference[oaicite:12]{index=12}
Test Voltage (cable) 2,000 V AC :contentReference[oaicite:13]{index=13}
Impulse Voltage Rating 1.5 kV :contentReference[oaicite:14]{index=14}
IP / Ingress Protection Rating IP65 / IP66K / IP67 (sealed-cable connector) :contentReference[oaicite:15]{index=15}
Operating Temperature Range Flexible: –5 °C … +80 °C; Stationary: –30 °C … +80 °C; Connector head: –25 °C … +85 °C :contentReference[oaicite:16]{index=16}
Approvals / Certifications UL (File No. E335179), RoHS compliant, flame-retardant per UL 1581 / CSA FT1 :contentReference[oaicite:17]{index=17}
Application / Use Sensor/actuator connection cable — industrial automation, industrial sensors, field cabling :contentReference[oaicite:18]{index=18}
