1221531 | SICK SENSORS | KTX-WB9214225AZZZZZZZZDZZZZZZ1 Contrast Sensor

₹ 64,384.45

₹ 54,563.10 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

1221531

Original Equipment Manufacturer

SICK SENSORS

Descripción
Special applications Standard
Device type Standard
Dimensions (W x H x D) 30 mm x 53 mm x 78.5 mm
Sensing distance ≤ 13 mm
Sensing distance tolerance ± 5 mm
Housing design Large
Light source LED, RGB 1)
Wave length 470 nm, 525 nm, 625 nm
Light emission Short device side
Light spot size 3.8 mm x 0.9 mm
Light spot direction Horizontal 2)
Receiving filters None
Teach-in mode 1-point teach-in, 2-point teach-in, teach-in dynamic, auto mode
Output function Light/dark switching
Delay time Adjustable
Special features Compressed air inlet
Delivery status 2-point teach-in
Housing material VISTAL®
Optics material Glass
Connection type Plug, M12, 5-pin
Weight 94 g
