XS1M12PA370 | TELEMECANIQUE SENSORS | Inductive Sensor XS1 M12, 12…48VDC

₹ 6,726.00

₹ 5,700.00 (Excl. Tax)

Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.

Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

XS1M12PA370

Original Equipment Manufacturer

TELEMECANIQUE SENSORS

Descripción
Specification Details
Manufacturer Telemecanique Sensors
Part Number XS1M12PA370
Product Type Inductive Proximity Sensor (General Purpose) :contentReference[oaicite:1]{index=1}
Series / Range OsiSense XS, XS1 series :contentReference[oaicite:2]{index=2}
Thread / Housing Cylindrical M12 × 1 thread :contentReference[oaicite:3]{index=3}
Rated Supply Voltage (Us) 12 … 24 V DC with reverse-polarity protection :contentReference[oaicite:4]{index=4}
Switching Capacity ≤ 200 mA with overload & short-circuit protection :contentReference[oaicite:5]{index=5}
Switching Frequency ≤ 1 000 Hz :contentReference[oaicite:6]{index=6}
Maximum Voltage Drop (closed state) < 2 V :contentReference[oaicite:7]{index=7}
Current Consumption (no-load) 0…10 mA :contentReference[oaicite:8]{index=8}
Operating Temperature Range -40 °C … +70 °C :contentReference[oaicite:9]{index=9}
Vibration Resistance 25 g amplitude ±2 mm, 10-55 Hz :contentReference[oaicite:10]{index=10}
Shock Resistance 50 g for 11 ms :contentReference[oaicite:11]{index=11}
Status LED 1 LED (yellow) for output state :contentReference[oaicite:12]{index=12}
Detection Face Material PPS (polyphenylene sulphide) :contentReference[oaicite:13]{index=13}
Mounting Note Flush or non-flush mounting; sensor is now discontinued with replacement recommended. :contentReference[oaicite:14]{index=14}
