052018 | PEPPERL+FUCHS | Inductive Sensor

₹ 11,800.00

₹ 10,000.00 (Excl. Tax)


Warranty

We provide a 1-year warranty from the date of purchase for new products. Additionally, surplus / used items come with a 30-day warranty.

Delivery and Shipping

We aim to process orders within 5-7 business days. Shipping options vary by location with tracking provided; international shipping available with customs duties responsibility on customers.


Enquire Now
Interested in this product? Submit your enquiry by entering your details.

Manufacturer Part Number (MPN)

052018

Original Equipment Manufacturer

PEPPERL+FUCHS

Description

Parameter Specification
Product series / family name NBB
Ambient air temperature for operation -25...+70 °C
Main function Sensor (Proximity; inductive)
Functions Inductive proximity sensor
Coating material Nickel plating
Material Brass (housing) / LCP (sensing face)
Degree of protection IP67
Sensing distance 2 mm
Visual position indicator Yellow LED (switching state)
Digital outputs 1 x digital output (PNP)
Connection type Pre-wired
Compliant with standard(s) UL / CSA / CCC
Supply voltage DC 10–30 V
Length (cable) 2 m
Diameter M8 / 8 mm
Operating mode NO (Normally Open)
Protection functions Reverse polarity / Short-circuit (pulsed)
Mounting mode Flush mounting
Shape Cylindrical threaded
Type Inductive (proximity detection)
Number of circuits 3-wire
Sampling rate 3000 Hz
Control circuit rated current 0.1 A / 100 mA
